Description
Sargent RX-8271-24V LNJ 26D Electric Mortise Lock Fail Secure with Request To Exit, LN Rose, J Lever, 12 Volts, LA Keyway, US26D/626 Satin Chrome
The RX-8271-24V LNJ 26D Is a Sargent 24V Electrified Fail Secure Mortise Lock, with an LN Rose, J Lever, with Request To Exit and comes in a Satin Chrome Finish.
Product Specs
| Manufacturer | Sargent |
| Grade | Grade 1 |
| Origin | USA |
| Unit of Measure | Each |
| Application | Complete Lock |
| Base Material | Brass or Bronze |
| BAA Qualified | Yes |
| Limited Warranty | 2 Years |
| Fire Rated | 2 Hours {B} |
| Finish | 626/US26D |
| Finish Description | Satin Chrome |
Technical Specs
| Function | 71 Electrical Fail Secure |
| Lever/Knob Design | J - Lever |
| Rose/Escutcheon Design | LN Rose (2" Diameter) |
| Cylinder Type | Conventional Cylinder |
| Num Pins | 6 |
| Keyway | LA |
| Keying | Keyed Different |
| Key(s) | Cut |
| Number of Keys | 2 |
| Hand | Field Reversible |
| Door Thickness | 1-3/4" |
| Bolt Projection | 3/4" |
| Strike Number | 82-0110 |
| Strike Type | ASA |
| Strike Height | 4-7/8" |
| Strike Width | 1-1/4" |
| Screws | Combination |
| Power | Hard Wired |
| Operating Voltage | 24VDC |
| Amp Draw | 500mA Peak, 15mA Holding |
| Switch Type | RX |
| Product Type | Electric Mortise Loc |
Product Reviews
Document Center
Handing Chart
