Sargent 8813 ETL Rim Exit Device Panic Bar
ETL Trim
Sargent 12-8813-G-ETL Fire Rated Rim Exit Device Panic Bar, Key Locks Or Unlocks Outside Lever, 43"-48" Bar, ETL Trim
Sargent 12-8813-G-ETL Fire Rated Rim Exit Device Panic Bar, Key Locks Or Unlocks Outside Lever, 43"-48" Bar, ETL Trim
Sargent 8813 ETL Rim Exit Device Panic Bar
ETL Trim
Sargent 12-8813-G-ETL Fire Rated Rim Exit Device Panic Bar, Key Locks Or Unlocks Outside Lever, 43"-48" Bar, ETL Trim
Sargent 12-8813-G-ETL Fire Rated Rim Exit Device Panic Bar, Key Locks Or Unlocks Outside Lever, 43"-48" Bar, ETL Trim

Sargent 12-8813-G-ETL Fire Rated Rim Exit Device Panic Bar, Key Locks Or Unlocks Outside Lever, 43"-48" Bar, ETL Trim

Brand: SARGENTSKU: 128813GETLUS32DLHR
Finish: US32D Satin Stainless Steel (630)
Core Options: KD - Sargent Fixed Core LA Keyway Keyed Different with 2 Change Keys per Lock
Sargent Handing: '-LHR, Left Hand Reverse
Price:
$1,507.88/ea
In Stock
In Stock

Related Hardware

Sargent 8504-ETL
SARGENT Sargent 12-8504-G-ETL Fire Rated Narrow Stile Rim Exit Device, Night Latch Function, 43"-48" Bar, ETL Trim
From $1,638.77
Choose options
8804-ETL-US32D
SARGENT Sargent 12-8804-G-ETL Fire Rated Rim Exit Device, Night Latch Function, 43"-48" Bar, ETL Trim
From $1,576.42
Choose options
Sargent 12-8866-G-PTB Fire Rated Rim Exit Device Panic Bar Key Lock/Unlock, 43"-48" Bar, PTB Trim
SARGENT Sargent 12-8866-G-PTB Fire Rated Rim Exit Device Panic Bar Key Lock/Unlock, 43"-48" Bar, PTB Trim
From $1,406.68
Choose options
Sargent 12-8713-G-ETL-84-US32D Surface Vertical Rod Exit Device
SARGENT Sargent 12-8713-G-ETL-84 Surface Vertical Rod Exit Device, Fire rated Key Locks Or Unlocks Outside Lever, 84" Height, 43"-48" Bar, ETL Trim
From $2,143.75
Choose options

The Sargent 12-8813-G-ETL Rim Exit Device Panic Bar is Fire Rated, a 43"-48" bar, and features a ETL Trim.

This is an exit device panic bar ideal for use in all institutions, office spaces, and healthcare facilities. It is grade 1 commercial door hardware.

A key locks/unlocks the outside lever control, and the Sargent 8813 has "ETL" trim.

Features: Sargent 12-8813 Rim Exit Device Panic Bar

  • Single-point rim latching device
  • Single door & double door applications with mullions
  • Quiet operation and solid security
  • Devices are ANSI A156.3 - Grade 1
  • UL Fire and Panic listed
Manufacturer Sargent
Grade Grade 1
Installation Commercial
Origin USA
Unit of Measure Each
UL Listing Type UL10C & UL305
ANSI Number ANSI/BHMA A156.3
Restrictions None
BAA Qualified Yes
Limited Warranty 5 Years
Fire Rated 3 Hours {A}
Burglar Rated No
ADA Compliance Yes

Sargent 12-8813 Rim Exit Device Panic Bar

Physical Appearance Wide Stile Pushpad
Device Type Rim
Mechanical Function Classroom
Device Length 48"
Hand LHR or RHR
Dogging Options Less Dogging
Includes Trim Yes
Trim Type ETL
Includes Cylinder(s) Optional
Minimum Stile Size 4-3/4"
Door Material Metal or Wood
Door Width 43" to 48"
Door Thickness 1-3/4" - 2-1/4"
Fire Rated Yes
Reversible No
Product Type Rim Exit Devices


Product Cut Sheet

Panic Handing Chart
